| Quantity(Pieces) | 1 - 100 | >100 |
| Est. Time(days) | 7 | To be negotiated |
We depend on sturdy technical force and continually create sophisticated technologies to fulfill the demand of Supply OEM/ODM Ce Automatic Transfer Switch ATS 2pole 230V 63A, We welcome new and old shoppers to make contact with us by telephone or mail us inquiries by mail for foreseeable future company associations and attaining mutual achievements.
We depend on sturdy technical force and continually create sophisticated technologies to fulfill the demand of China Transfer Switch and Electrical Switch, Our company absorbs new ideas, strict quality control, a full range of service tracking, and adhere to make high-quality products. Our business aims to “honest and trustworthy, favorable price, customer first”, so we won the trust of the majority of customers! If you are interested in our goods and services, please do not hesitate to contact us!
Product detail
Model | YES1-SA,YES1-S,YES1-L | ||||||||||
Insulation voltage | AC690V | ||||||||||
Rated voltage | AC400V | ||||||||||
Rated current | 20A-125A | 160A-250A | 315A-630A | ||||||||
The rated impulse withstand voltage(kV) | 8 | ||||||||||
Using classes | AC-33iB | ||||||||||
Vote number | Double vote | ||||||||||
Writing manner | Before the board | ||||||||||
Pole | 2P | 3P | 4P | 2P | 3P | 4P | 2P | 3P | 4P | ||
Weight | 6 | 6.3 | 7 | 6 | 8 | 10 | 11 | 13.6 | 16.2 | ||
characteristic | short time withstand current | 10kA | 12.6kA | ||||||||
Connect sub-capactiy | 6le | 6le | |||||||||
Service life | 6000times/20000times | 1000times/4000times | |||||||||
Operating cycle | 60times/hour | ||||||||||
Auxiliary switch | A,B side power both with 2 normally open and 2 normally closed;switch capacity | ||||||||||
15A/AC250V | |||||||||||
Weight(kg) | Manual handle | ||||||||||
| Name | Content |
| Enterprise code | Shanghai Yuhuang electric co.,ltd |
| Product category | PC class Automatic Transfer Switch |
| Design code | 1 |
| Current rank | NA/N/C:32A,125A,250A,400A,630ASA/S/LA/L:125A,250A,630AG:100A,250A,630A,1600A,3200AM:1600A AQ:3200A |
| Product code | NA:16A~630A(Integral type,two positions)N:16A~630A(Split type,two positions)C:16A~630A(Split type,two positions)M:630A~1600A(Split type,two positions)Q:630A~3200A(Split type,two positions)SA:20A~630A(Integral type,Three positions)S:20A~630A( Split type,Three positions) LA:20A~630A(Integral type,Two positions) L:20A~630A(Split type,two positions) G:GA:16A~3200A(With fire protection function) GA1:16A~100A(Without fire protection function) |
| Pole | 2P(125A and below 125A products),3P,4P |
| Rated current | 16A~3200A |
| Working mode | R=Self-input and self-recoverS=Self-input without self-recoverF=Utility-Generator |
