Product detail
Model | YES1-250(NA/N/C) | YES1-400(NA/N/C) | YES1-630(NA/N/C) | |||||
Rated current(A) | 160,180,200,225,250 | 250,315,400 | 500,630 | |||||
Rated control current(A) | 7 | |||||||
Rated short time current(kA) | 10 | |||||||
The rated impulse withstand voltage(kV) | 8 | |||||||
Using classes | AC-33B | |||||||
Service | Mechanical | 17000 | ||||||
Electric | 6000 | |||||||
Pole | 3P | 4P | 3P | 4P | 3P | 4P | ||
Weight(kg) | 18 | 19 | 18.5 | 20.5 | 20 | 22 | ||
Operating cycle(s/time) | 15 | |||||||
| Name | Content |
| Enterprise code | Shanghai Yuhuang electric co.,ltd |
| Product category | PC class Automatic Transfer Switch |
| Design code | 1 |
| Current rank | NA/N/C:32A,125A,250A,400A,630ASA/S/LA/L:125A,250A,630AG:100A,250A,630A,1600A,3200AM:1600A AQ:3200A |
| Product code | NA:16A~630A(Integral type,two positions)N:16A~630A(Split type,two positions)C:16A~630A(Split type,two positions)M:630A~1600A(Split type,two positions)Q:630A~3200A(Split type,two positions) SA:20A~630A(Integral type,Three positions) S:20A~630A( Split type,Three positions) LA:20A~630A(Integral type,Two positions) L:20A~630A(Split type,two positions) G:GA:16A~3200A(With fire protection function) GA1:16A~100A(Without fire protection function) |
| Pole | 2P(125A and below 125A products),3P,4P |
| Rated current | 16A~3200A |
| Working mode | R=Self-input and self-recoverS=Self-input without self-recoverF=Utility-Generator |
