We support our buyers with ideal high quality products and high level service. Becoming the specialist manufacturer in this sector, we have gained rich practical experience in producing and managing for OEM Factory for China Automatic Transfer Switch Intelligent ATS, We would like to acquire this prospect to determine long-term business enterprise interactions with purchasers from all around the planet.
We support our buyers with ideal high quality products and high level service. Becoming the specialist manufacturer in this sector, we have gained rich practical experience in producing and managing for China ATS, Dual Power, Many years of work experience, now we have realized the importance of providing good quality products and solutions and the best before-sales and after-sales services. Most problems between suppliers and clients are due to poor communication. Culturally, suppliers can be reluctant to question points they do not understand. We break down those barriers to ensure you get what you want to the level you expect, when you want it. faster delivery time and the product you want is our Criterion .
Note: 63A Shell grade products,there are two in and two in and two out,two connection methods are available.
Product featur
This type intelligent dual power automatic switchs the mechanical interlocking transmission,intelligent controller and other components. It has the integral style and split type with two kinds mechanism. Integral controller is equipped with a base and executing agencies.
Split type is intelligent controller installed in the panel User take the base by implementing agencies to install into the cabinet controller with an about 2m cables.
1.Reliable mechanical interlock between the two circuit breakers and electrical interlock device. Eliminate the two devices closing completely at the same time.
2.SCM intelligent controller used to control the core hardware is simple and powerful,expansion of convenience,high reliability.
3.It has a short circuit,over load protection functions,over voltage,under voltage,loss phase automatic transfer function and intelligent alarm function.
4.Automatic switching external parameters can be set free.
5.Operation of intelligent motor protection.
6.The control circuit devices with fire, fire control center to a control signal into intelligent controller. Two sets circuit breaker will enter a stating of breaking.
7.There is a computer network interface for achieving remote control four remote telemetry functions.
Working conditions
1.Ambient air temperature of -5℃ to +40℃,and at 24 hour average temperature does not exceed +35℃.
2.The installation location no more than 2000meters.
3.The maximum temperature of +40℃,the air relative humidity is no more than 50%,at a low temperature can be allowed to have a higher relative humidity, such as 20℃ at 90%. Special measures should be taken for occasional condensation due to temperature changes.
4.Pollution level:grade Ⅲ.
5.Installation category:Ⅲ.
6.The two power lines are connected to the upper side of the switch,and the load line is connected to the lower side.
7.The location of installation should not have significant vibration,impact.
| Name | Content |
| Enterprise code | Shanghai Yuhuang Electric Co.,Ltd |
| Product category | CB class Automatic Transfer Switch |
| Design code | 3 |
| Current rank | 63,125,250,630 |
| Product code | None(Two input and one output)(acquiescene);E(Two input and two output)(63A) |
| Controller | W1:(Integrated intelligent type)(acquiescene)W2:(LED split intelligent type)(125A,250A,630A)W3:(LCD split intelligent type)(125A,250A,630A) |
| Pole | 4P |
| Rated current | 16A~630A |
| Working mode | R(Self-input and self-recover)S(Self-input without self-recover)B(Mutual reserve)T(Communication) |
| Name | Content |
| Enterprise code | Shanghai Yuhuang electric co.,ltd |
| Product category | PC class Automatic Transfer Switch |
| Design code | 1 |
| Current rank | NA/N/C:32A,125A,250A,400A,630ASA/S/LA/L:125A,250A,630AG:100A,250A,630A,1600A,3200AM:1600A AQ:3200A |
| Product code | NA:16A~630A(Integral type,two positions)N:16A~630A(Split type,two positions)C:16A~630A(Split type,two positions)M:630A~1600A(Split type,two positions)Q:630A~3200A(Split type,two positions) SA:20A~630A(Integral type,Three positions) S:20A~630A( Split type,Three positions) LA:20A~630A(Integral type,Two positions) L:20A~630A(Split type,two positions) G:GA:16A~3200A(With fire protection function) GA1:16A~100A(Without fire protection function) |
| Pole | 2P(125A and below 125A products),3P,4P |
| Rated current | 16A~3200A |
| Working mode | R=Self-input and self-recoverS=Self-input without self-recoverF=Utility-Generator |
We support our buyers with ideal high quality products and high level service. Becoming the specialist manufacturer in this sector, we have gained rich practical experience in producing and managing for OEM Factory for China Automatic Transfer Switch Intelligent ATS Swq1yj-100m, We would like to acquire this prospect to determine long-term business enterprise interactions with purchasers from all around the planet.
OEM Factory for China ATS, Dual Power, Many years of work experience, now we have realized the importance of providing good quality products and solutions and the best before-sales and after-sales services. Most problems between suppliers and clients are due to poor communication. Culturally, suppliers can be reluctant to question points they do not understand. We break down those barriers to ensure you get what you want to the level you expect, when you want it. faster delivery time and the product you want is our Criterion .
